ITECH | DC Power Supply

ITech IT6872A

Rs. 43740.00

The ITECH IT6872A is a precision programmable DC power supply offering 150V, 2A, and 300W output, ideal for high-voltage device testing and R&D labs. With advanced protection, excellent resolution, and SCPI compatibility, it delivers stable, accurate, and noise-free power for sensitive electronic applications, while supporting seamless communication via USB and RS232..

  • Detail
  • Special Features
  • Specification

The IT6872A enables engineers and developers to precisely control voltage and current parameters for high-voltage components and systems. Its 300W capacity ensures dependable output even during demanding load transitions, while its compact footprint makes it suitable for dense lab benches or test racks.

Its built-in list mode allows for complex test sequences without external control, and multiple protection features help prevent damage to both the power supply and the device under test. Backed by ITECH’s proven reliability, it’s an ideal choice for automated test systems, industrial electronics, and advanced prototyping.

  • Output range: 0–150 V / 0–2 A

  • 1 mV / 0.1 mA high-resolution LED display

  • Very low ripple and noise performance

  • Overvoltage, overcurrent, and overtemperature protection

  • LIST/STEP programmable output sequencing

  • Fast transient response time and load recovery

  • USB and RS232 standard communication interfaces

  • Compact benchtop design with built-in SCPI command support

Parameter Value
Output Voltage 0 – 150 V
Output Current 0 – 2 A
Output Power 300 W
Load Regulation ≤ 0.01% + 3 mV (Voltage), ≤ 0.2% + 3 mA (Current)
Line Regulation ≤ 0.01% + 3 mV (Voltage), ≤ 0.2% + 3 mA (Current)
Ripple & Noise ≤ 1 mVrms / ≤ 3 mArms
Display Resolution 1 mV / 0.1 mA
Programming Time < 50 ms
Protection OVP, OCP, OTP, Foldback
Communication Interfaces USB, RS232
Dimensions (W×H×D) 225 × 100 × 320 mm
Weight Approx. 4.5 kg
Operating Temperature 0 °C to 40 °C
Warranty 1 Year Manufacturer Warranty
